DuPont™ AmberLite™ IRC120 N Gaussian, Gel, Strong Acid Cation Exchange Resin
Λεπτομέρειες:
| Τόπος καταγωγής: | ΚΙΝΑ |
| Μάρκα: | Dupont |
| Πιστοποίηση: | ISO9001 |
| Αριθμό μοντέλου: | Dupont ™ Amberlite ™ IRC120 NA |
| Έγγραφο: | IER-AmberLite-IRC120-Na-PDS...en.pdf |
Πληρωμής & Αποστολής Όροι:
| Ποσότητα παραγγελίας min: | 1PC |
|---|---|
| Τιμή: | διαπραγματεύσιμα |
| Συσκευασία λεπτομέρειες: | τυπική συσκευασία εξαγωγής |
| Χρόνος παράδοσης: | 5-8 εργάσιμες ημέρες |
| Όροι πληρωμής: | T/t |
| Δυνατότητα προσφοράς: | 60000 μονάδες το μήνα |
|
Λεπτομερής ενημέρωση |
|||
| Συμπολυμερές προϊόντων: | Στυρενίου-διζινυλοβενζόλιο | Τύπος προϊόντος: | Ισχυρό κατιόν οξέος |
|---|---|---|---|
| Λειτουργική ομάδα προϊόντος: | Σουλφονικό οξύ | Πρωτογενείς εφαρμογές προϊόντος: | Βιομηχανική μαλακτοποίηση νερού |
| Φυσική μορφή: | Κεχριμπάρι ημιδιαφανή σφαιρικά σφαιρίδια | Ιοντική μορφή (όπως αποστέλλεται): | Ναρ |
| Συνολική ικανότητα ανταλλαγής: | ≥ 2,0 eq/l (μορφή na⁺) | Δυνατότητα συγκράτησης νερού: | 40.0 - 50,0% (μορφή NA⁺) |
Περιγραφή προϊόντων
1. Product Overview
DuPont™ AmberLite™ IRC120 Na is a gaussian, gel-type, strong acid cation exchange resin designed for industrial water softening applications. With a long-established track record of reliable performance, this durable resin offers an optimal balance of high capacity and mechanical strength, making it ideal for co-current regenerated systems in industrial water treatment. It is also suitable for demineralization applications where the sodium form is preferred.
2. Applications
-
Industrial water softening
-
Demineralization (when sodium-form resin is specified)
3. Compatible System Designs
-
Co-current regeneration systems
4. Historical Reference
Previously sold as AmberLite™ IR120 Na Ion Exchange Resin.
5. Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Amber translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Na⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (Na⁺ form) |
| Water Retention Capacity | 40.0 – 50.0% (Na⁺ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| < 300 μm | ≤ 2.0% |
| > 1180 μm | ≤ 4.0% |
ℹ For additional particle size information, refer to Document No. 45-D00954-en.
6. Stability & Density
-
Swelling (Na⁺ → H⁺): ≤ 11%
-
Particle Density: 1.27 g/mL
-
Shipping Weight: 817 – 840 g/L
7. Operating Conditions
-
Temperature Range (Na⁺ form): 5 – 150°C (41 – 302°F)
-
pH Range:
-
Service Cycle: 1 – 14
-
Stable: 0 – 14
-
⚠ For detailed information on minimum bed depth, operating conditions, and regeneration procedures, refer to Tech Fact Document No. 45-D01131-en.
8. Hydraulic Characteristics
-
Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
-
Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water and well-classified beds at service run start).
(Note: Refer to original document for graphical data.)
9. Safety & Compliance
-
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
-
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
